high quality Ticket dispenser machine for game machine
Type:Coin Pusher Brand Name:LOYOYO
Age:>6 Years Type: arcade parts:Color: white
Rated Current: 0.5A~10A:Place of Origin:
Guangdong, China (Mainland)
Product Description
2pcs high quality Ticket dispenser machine for game machine
1. Adapt to the machine, Switch to SW1, to choose OV low level or +5V high level as the effective signal of x input voltage.
2. Adapt to the machine, Switch to SW2 to choose N. O. (Normally Open) or N. C. (Normally dose)as the output Sw3 for adjusting the ticket to the best site of ticket-out.
3. First put the ticket into the machine, turn on the test button Sw3 for adjusting the ticket to the best site of ticket-out
4. The fault light on the panel will always power on when ticket is not locket; The light will
Power off. It twinkles according to the number of ticket-out.
5. Has a reverse function, so that field maintenance easier;
6. Connect:
White Line----In(Signal input cable)
Black Line---Ground
Red Line---DC+12V
Green Line----OUT(Signal output line)
Function:
1,Program control and counting precision
2,Speed ticket
3,Has a reverse function
Product parameters:
Voltage: DC+12V+10%
Ticket width: 29mm
Ticket length: 50mm~120mm
Package: 20 PCS/ctn
Dimension: 540*275*270
Currents: 70mA ~ 700 mA
Temperature:-10°C~+50°C
| We offer good quality PC Board, Video Game, Multi Game, Multi Cartridge, Vending machine, Pinball Machine, Kiddy Rides, ABS cabinet available for 21"~25"monitor, heavy steel cabinet for 25"~29" monitor with Jamma connector, and some spare parts, Coin Acceptor, pushbutton, joystick, etc. For Amusement machines. Please contact to me if you are interested in our products, we will send you the datas in details. |
Note:
1.As every country have different policy for import tax,so our price is not include import tax. Please check your local tax before buying. Brazil customer if goods sent by EMS but can not receive goods for long time after goods sent out,please contact local post office.
2.Ship cost is base if your place is not remote area.If your place is remote area then should add USD$30 for extra fee.
3.If you want to change shipping method,if your order is combine order,please confirm your order but not pay,and contact us to adjust.
We have many kind of arcade parts and arcade game pcb.You can build or replace your machine with convenience way.
Our product brand include: Sanwa,Seimistsu,Zippy,WeiYa and other local brand with good quality.
Our parts include:Joystick ,Push Button, Microswitch ,Speaker ,Cooler Fans ,Coin acceptor,Power supply,Cable Holder,Jamma Harness,PCB Feet,Track Ball,Cam Locks,Coin Door,Converter Board and so on.
Our game board include: 2100 In 1,2019 in 1,1940 In One,1078 In 1,1072 In 1,700 in 1,485 in 1,450 In 1,200 In 1,Neo Geo cassette SNK 161 in 1,151 In 1,138 In 1,120 In 1,111 In 1,100 In 1,48 In 1,45 In 1,38 In 1,32 In 1...
Game Family,Baby Star,Game Elf, Just Another Pandora's Box ,Happy Fish II-302 In 1,Happy Fish I-195 In 1,Blue Elf II-310 In 1,Blue Elf I-108 In 1,Classic 60 In 1.......
Our casino Game PCB include: Red Boad multi XXL ,7X,6X,Coolair, Gaminator ,16 in 1,9 in 1,7 in 1 and so on...
Packaging Details
Unit Type:
piece
Package Weight:
1.000kg (2.20lb.)
Package Size:
20cm x 15cm x 10cm (7.87in x 5.91in x 3.94in)
